SKF FNL 522 B Square Flanged Housing For Bearing On An Adapter Sleeve

Description

FNL flanged housings are well-proven machine parts that provide simple, reliable housing in applications without horizontal frames. FNL flanged housings are non-split housings that are produced in two designs depending on size. Smaller sizes up to and including size FNL 13 have a triangular flange, larger sizes have a square flange.The housings are supplied with a cover either for shaft ends or for through shafts. The housings with a cover for shaft ends have the designation suffix A, the housings with a cover for through shafts have the designation suffix B.FNL flanged housings are made of grey cast iron.Specifications Shaft diameter da: 100mm. Inside space length Ca: 63mm. Spherical seat diameter Da: 200mm. Base width A: 98mm. Flange width A1: 30mm. Overall width for through shaft AB: 137mm. Distance bearing side face to housing bottom Ba: 30mm. Outside diameter housing cover D: 244mm. Complete housing height H: 270mm. Spherical seat centre height H1: 135mm. Distance between attachment bolts J: 219mm. Overall length L: 270mm. Diameter of attachment bolt hole N: 22mm. Distance between dowel pins J5: 122mm. Distance between dowel pins J6: 78mm. Diameter of dowel pins N4max: 8mm. Breaking loads P1: 190kN. Breaking loads P2: 200kN. Breaking loads P3: 640kN. Cover bolt, size: M 10x30. Cover bolt, rec. tightening torque: 47Nm. Appropriate attachment bolt, size G: 20mm. Appropriate attachment bolt, rec. tightening torque: 385Nm. Initial grease fill, 20%: 420g Recommended bearings: 1222 K, 2222 K, 22222 K, C 2222 K Recommended sleeve: H 222, H 322, H 322 E

Brand: SKF
Category: Motor Vehicle Transmission & Drivetrain Parts

Fruugo ID: 51271715-102888752
EAN: 5059633249022
